A 55-inch Full HD ADS display unit for professional video walls. Its 3.5 mm combined bezel, 500 cd/m² brightness, continuous-operation design and video loop connections suit monitoring centres and large multi-screen information displays.
Key specifications
- Model: DHI-LS550UCM-EF
- Resolution: 1920 × 1080 (Full HD)
- Aspect ratio: 16:9
- Display: 55″
- Panel: ADS
- Interface: Inputs: 1 × HDMI, 1 × VGA, 1 × DVI-D, 1 × CVBS/BNC, 1 × RS-232/RJ45, 2 × USB, 1 × audio in, 1 × IR; outputs: 2 × HDMI, 1 × VGA, 1 × CVBS, 1 × RS-232/RJ45, 1 × audio out
- Brightness: 500 cd/m²
- Response time: 8 ms
- Contrast: 1400:1
- VESA mount: 600 × 400 mm
- Operation hours: 24/7
- Dimensions: 1213.7 × 684.5 × 106.5 mm
- Weight: 35 kg
A video-wall module requiring suitable mounting hardware. The RJ45-style connector is RS-232 control, not an Ethernet network port. This specification matches the older 1400:1, 35 kg configuration.
