Cudy GS1010PE — 10-Port Gigabit PoE Switch

A Gigabit switch with eight PoE ports and two dedicated uplinks. Supports IEEE 802.3af/at power delivery and hardware VLAN/Extend modes (Extend: 10 Mbps).

Key specifications

• Model: Cudy GS1010PE
• Ports and interfaces: 10 × RJ45
• Network port count: 10 (10 × RJ45)
• Per-port speed: 10 × RJ45: 10/100/1000 Mbps
• PoE support: IEEE 802.3af/at; 8 PoE ports; up to 30 W per PoE port
• Uplink connections: 2 × RJ45 (10/100/1000 Mbps)
• Management: Unmanaged; hardware Default/VLAN/Extend modes
• Switching capacity: 20 Gbps; 14.88 Mpps
• Power: 100-240 V AC 50/60 Hz; power supply: 120 W
• Mounting: Desktop or rackmount; brackets sold separately
• Dimensions: 220 × 163 × 40 mm

In Extend mode, ports 7–8 support up to 250 m at 10 Mbps. The stated power-supply rating is not a specification of total PoE output budget.
