Cudy C200P Gigabit VPN Router and AP Controller

Gigabit VPN router and Cudy access-point controller with four PoE+ LAN ports, one WAN port and USB 3.0. With DC power, the PoE budget is up to 55 W, reduced to 50 W when a USB device is connected.

Key specifications

• Model: Cudy C200P
• Ethernet port count: 5
• Ethernet port speed: 10/100/1000 Mbps
• Network ports: 1× WAN + 4× LAN (PoE+)
• Wi-Fi standard: No integrated Wi-Fi
• Power: 54 V / 1.11 A DC
• PoE: 4× PoE+ outputs, 802.3af/at, up to 30 W/port, 55 W total (50 W with USB)
• USB port: 1× USB-A 3.0 (5 V / 1 A)
• Managed AP capacity: Up to 200 APs in controller-only mode; router + controller: 10 APs recommended
• Management: Web management, AP controller, VPN
• Operating modes: VPN router + AP controller / AP controller only
• Mounting: Desktop or wall
• Body dimensions: 190×100×28 mm
• Processor: 880 MHz Dual-Core
• Memory: RAM: 256 MB DDR3; flash: 16 MB NOR
• Alternative power input: 802.3af/at PoE or 24–48 V passive PoE; PoE outputs are disabled with these inputs

PoE outputs work only with DC power. When using an external portal server, the manufacturer recommends managing fewer than 200 APs.

Official Cudy specifications
