Cudy AP3000 Outdoor Outdoor Wi-Fi 6 Access Point

Outdoor AX3000 Wi-Fi 6 access point with one Gigabit Ethernet port and an IP65 enclosure. Supports 802.3at PoE or 48–57 V passive PoE and wall or pole mounting.

Key specifications

• Model: Cudy AP3000 Outdoor
• Ethernet port count: 1
• Ethernet port speed: 10/100/1000 Mbps
• Network ports: 1× RJ45 (PoE In)
• Uplink: 1× Gigabit Ethernet with PoE input
• Wi-Fi standard: Wi-Fi 6
• Wi-Fi bands: 2.4 GHz / 5 GHz
• Maximum Wi-Fi PHY rates: 2.4 GHz: 574; 5 GHz: 2402 Mbps (PHY)
• Power: 802.3at PoE / 48–57 V Passive PoE
• PoE: Input: 802.3at PoE / 48–57 V Passive PoE
• Protection rating: IP65 when installed vertically
• Management: Web management; Cudy Mesh
• Operating modes: Wi-Fi router / Access point / Range extender / WISP / Client
• Mounting: Wall or pole
• Body dimensions: 240×100×53.7 mm
• Wi-Fi antennas: 1× internal + 2× detachable external
• Processor: 1.3 GHz Dual-Core CPU
• Memory: RAM: 256 MB DDR3; flash: 128 MB NAND

Wi-Fi rates are theoretical PHY maxima; actual throughput depends on devices, environment and connection conditions.
